Light Source |
LED White light |
|
Aiming Light |
Green Dot |
|
Image Sensor |
1280*800 pixels (Global Shutter) |
|
CPU |
1.2G Dual core |
|
Resolution(maximum) |
3mils |
|
Minimum Print Contrast |
20% Reflection Difference |
|
Motion Tolerance |
2M/S |
|
Image Field of View |
Horizontal: 50°; Vertical: 38° |
|
Reading Angle |
Pitch: 0-360°; Roll(Tilt): ±60°; Skew (Yaw): ±60° |
|
Decoding Capability |
1D: All standard 1D codes including GS1 DataBar™ linear code can be automatically distinguished and decoded.
2D: Aztec Code; Data Matrix; MaxiCode; QRCode; HANXIN; MicroQR Code
Stack code: GS1 DataBar Expanded Stacked; GS1 DataBar Stacked; GS1 DataBar Stacked Omnidirectional; GS1 DataBar Composite; MicroPDF417; PDF417. |
|
Reading Indicators |
LED light&Buzzer(adjustable tone and volume） |
|
Typical depth of Field |
Precision Barcode Depth of Field
3.34mil CODE 39 60mm—160mm
3.34mil EAN-13 90mm—150mm
5mil CODE39 70mm—240mm
5mil EAN-13 70mm—230mm
13mil UPC-A 40mm—450mm
5mil PDF417 65mm—210mm
5mil QR 75mm—140mm
10mil QR 45mm—290mm
10mil DM 30mm—260mm
20mil QR 20mm—480mm
(The minimum depth of field is determined by the barcode length and scanning angle. It depends on the print resolution, contrast and ambient light.) |
