Light Source |
LED White light |
|
Aiming Light |
Green Dot |
|
Image Sensor |
800*600 pixels |
|
Resolution(maximum) |
3mils |
|
Minimum Print Contrast |
20% Reflection Difference |
|
Image Field of View |
D54°/H45°/V36° |
|
Reading Angle |
Pitch: 0-360°; Roll(Tilt): ±60°; Skew (Yaw): ±60° |
|
Decoding Capability |
1D: All standard 1D codes including GS1 DataBar™ linear code can be automatically distinguished and decoded.
2D: Aztec Code; Data Matrix; MaxiCode; QRCode; HANXIN; MicroQR Code
Stack code: GS1 DataBar Expanded Stacked; GS1 DataBar Stacked; GS1 DataBar Stacked Omnidirectional; GS1 DataBar Composite; MicroPDF417; PDF417. |
|
Reading Indicators |
LED light&Buzzer(adjustable tone and volume） |
|
Typical depth of Field |
Precision Barcode Depth of Field
3.34mil CODE 128 30mm—60mm
5mil CODE128 30mm—100mm
3.34mil EAN-13 35mm—60mm
5mil EAN-13 30mm—100mm
13.34mil EAN-13 30mm—230mm
5mil PDF417 30mm—100mm
10mil QR 30mm—150mm
10mil DM 20mm—125mm
(The minimum depth of field is determined by the barcode length and scanning angle. It depends on the print resolution, contrast and ambient light.) |
