Light Source |
LED White light |
|
Aiming Light |
Green Dot |
|
Image Sensor |
640*480 pixels (Global Shutter) |
|
CPU |
1.2G Dual core |
|
Resolution(maximum) |
3mils |
|
Minimum Print Contrast |
20% Reflection Difference |
|
Motion Tolerance |
2M/S |
|
Image Field of View |
Horizontal: 50°; Vertical: 38° |
|
Reading Angle |
Pitch: 0-360°; Roll(Tilt): ±60°; Skew (Yaw): ±60° |
|
Decoding Capability |
1D: All standard 1D codes including GS1 DataBar™ linear code can be automatically distinguished and decoded.
2D: Aztec Code; Data Matrix; MaxiCode; QRCode; HANXIN; MicroQR Code
Stack code: GS1 DataBar Expanded Stacked; GS1 DataBar Stacked; GS1 DataBar Stacked Omnidirectional; GS1 DataBar Composite; MicroPDF417; PDF417. |
|
Reading Indicators |
LED light&Buzzer(adjustable tone and volume） |
|
Typical depth of Field |
Precision Barcode Depth of Field
3.34mil CODE 128 40mm—80mm
5mil CODE128 35mm—135mm
3.34mil EAN-13 40mm—80mm
5mil EAN-13 30mm—105mm
13.34mil EAN-13 30mm—290mm
5mil PDF417 35mm—105mm
15mil QR 20mm—155mm
10mil DM 30mm—140mm
20mil QR 30mm—265mm
(The minimum depth of field is determined by the barcode length and scanning angle. It depends on the print resolution, contrast and ambient light.) |
