Light Source |
LED White light |
|
Image sensor |
640*480 pixels |
|
Resolution(maximum) |
0.102mm / 4mils |
|
Print contrast ratio(minimum) |
≥20% |
|
Reading Angle |
Pitch: 0-360°; Roll(Tilt): ±60°; Skew (Yaw): ±60° |
|
Decoding Capability |
1D: All standard 1D codes, including GS1 DataBar™ linear code can be automatically distinguished and decoded.
2D: Aztec Code; Data Matrix; MaxiCode; QRCode; HANXIN; MicroQR Code
Stack code: GS1 DataBar Expanded Stacked; GS1 DataBar Stacked; GS1 DataBar Stacked Omnidirectional; GS1 DataBar Composite; MicroPDF417; PDF417. |
|
Reading Indicators |
LED light&Buzzer(adjustable tone and volume） |
|
The typical depth of Filed |
Precision Barcode Depth of Filed
3.34mil CODE 128 10mm—60mm
5mil CODE128 5mm—90mm
3.34mil EAN-13 10mm—55mm
5mil EAN-13 5mm—85mm
13.34mil EAN-13 20mm—190mm
5mil PDF417 5mm—75mm
10mil PDF417 5mm—190mm
15mil PDF417 10mm—200mm
10mil DM 5mm—100mm
20mil DM 5mm—210mm
(The minimum depth of field is determined by the barcode length and scanning angle. It depends on the print resolution, contrast and ambient light.) |
