Light Source |
LED Red light（Germany） |
|
Image sensor |
640*480 pixels |
|
Resolution(maximum) |
0.102mm / 4mils |
|
Print contrast ratio(minimum) |
≥15% |
|
Motion tolerance |
2M/sec |
|
Reading Angle |
Pitch: 0-360°; Roll(Tilt): ±60°; Skew (Yaw): ±60° |
|
Decoding Capability |
1D: All standard 1D codes, including GS1 DataBar™ linear code can be automatically distinguished and decoded.
2D: Aztec Code; Data Matrix; MaxiCode; QRCode; HANXIN; MicroQR Code
Stack code: GS1 DataBar Expanded Stacked; GS1 DataBar Stacked; GS1 DataBar Stacked Omnidirectional; GS1 DataBar Composite; MicroPDF417; PDF417. |
|
Reading Indicators |
LED light&Buzzer(adjustable tone and volume） |
|
Typical depth of Filed |
Precision Barcode Depth of Filed
5mil CODE128 1mm—80mm
5mil EAN-13 1mm—80mm
13.34mil EAN-13 5mm—245mm
5mil PDF417 5mm—70mm
10mil PDF417 5mm—180mm
15mil PDF417 10mm—280mm
20mil DM 5mm—80mm
(The minimum depth of field is determined by the barcode length and scanning angle. It depends on the print resolution, contrast and ambient light.) |
