Light Source

Laser

Type of Light Source

650nm

Resolution(maximum)

0.102mm / 4mils

Print contrast ratio(minimum)

≥25%

Scan speed

120 times/s

Reading Angle

Tilt: ±65°;

Deflection: ±60°

Decoding Capability

Code128, EAN-13, EAN-8, Code39, UPC-A, UPC-E, Codabar, Interleaved 2 of 5, ISSN, ISBN, ISBT128, Code 93, UCC/EAN-128, GS1, Matrix 25 (Europe), MATRIX 25(Japan), Industrial25, ITF6, ITF14, RSS, Plessey, MSI-Plessey, Standard 25, Databar, Code11, Code32, Inverted Barcode, etc.

Reading Indicators

LED light&Buzzer(adjustable tone and volume）

Typical depth of Field

(The minimum depth of field is determined by the barcode length and scanning angle. It depends on the

print resolution, contrast and ambient light.)

Codes               Precision     Depth of Filed

CODE39           5mil            15-100mm

CODE128        10mil           15mm—210mm

CODE128        15mil           25mm—240mm

EAN13             10mil           95mm—370mm

Electrical Parameter

Current

Working status: 90-108 mA Standby: 70mA

Maximum power consumption

450mW

Environmental Parameter

ESD protection(Air discharge)

8 kV

Working Temperature

0 to 40 °C

Temperature

Storage/Transport: -40 to 70 °C

Drop resistance

can withstand multiple impacts from 1.2m/4.0ft drops to concrete

Humidity(non-condensing)

5 - 95%

Ambient light

Indoor: 0 to 6,000 lux; Outdoor: 0 to 86,000 lux

Product size

159*65.5*85mm

Weight

165g（not include cable）

Interfaces

RS-232; USB HID; USB COM

Transmission ways

Wired+2.4G+Bluetooth

Battery capacity

1800mA

Charging time

up to 3.5H

Working time with full power

more than 100,000 barcode

Warranty

1 Year
