Light Source

LED White light

Aiming Light

Green Dot

Image Sensor

800*600 pixels

Imaging Speed

60FPS

CPU

1.2G Dual core

Resolution(maximum)

3mil

Minimum Print Contrast

20% Reflection Difference

Image Field of View

D54°/H45°/V36°

Reading Angle

Pitch: ±65°; Roll(Tilt): 0-360°; Skew (Yaw): ±60°

Decoding Capability

1D: All standard 1D codes including GS1 DataBar™ linear code can be automatically distinguished and decoded.

2D: Aztec Code; Data Matrix; MaxiCode; QRCode; HANXIN; MicroQR Code

Stack code: GS1 DataBar Expanded Stacked; GS1 DataBar Stacked; GS1 DataBar Stacked Omnidirectional; GS1 DataBar Composite; MicroPDF417; PDF417.

Reading Indicators

LED light&Buzzer(adjustable tone and volume）

Typical depth of Field

Precision Barcode     Depth of Field

3.34mil    CODE128  30mm—60mm

5mil         CODE128  30mm—100mm

3.34mil    EAN-13     35mm—60mm

5mil         EAN-13     30mm—100mm

13.34mil  EAN-13     30mm—230mm

5mil         PDF417    30mm—100mm

10mil       QR            30mm—150mm

10mil       DM            20mm—125mm

(The minimum depth of field is determined by the barcode length and scanning angle. It depends on the print resolution, contrast and ambient light.)

Electrical Parameter

Current

Working current(Standard):

Input Voltage

5 VDC (+/- 5%)/500mA

Environmental Parameter

ESD protection

Touch discharge: 8 kV; Air discharge: 15kV

Drop resistance

Withstands repeated drops from 1.2m/4.0 ft onto a concrete surface.

Temperature

Working: -20 to 40 °C

Storage/Transport: -40 to 65 °C

Humidity(non-condensing)

5 - 95%

Ambient light

Indoor: 0 to 6,000 lux; Outdoor: 0 to 100,000 lux

Interface

USB HID; USB COM; RS-232; HID POS(OPOS/JPOS), optional interface

Transmission

Support multi-language transmission, compatible with major operating systems, support the editing of barcode data.

Warranty

24 months
