Light Source

LED White light

Aiming Light

Green Dot

Image Sensor

1280*800 pixels

CPU

1.2G Dual core

Resolution(maximum)

4mils

Minimum Print Contrast

20% Reflection Difference

Image Field of View

Horizontal: 50°; Vertical: 38°

Reading Angle

Pitch: 0-360°; Roll(Tilt): ±60°; Skew (Yaw): ±60°

Decoding Capability

1D: All standard 1D codes including GS1 DataBar™ linear code can be automatically distinguished and decoded.

2D: Aztec Code; Data Matrix; MaxiCode; QRCode; HANXIN; MicroQR Code

Stack code: GS1 DataBar Expanded Stacked; GS1 DataBar Stacked; GS1 DataBar Stacked Omnidirectional; GS1 DataBar Composite; MicroPDF417; PDF417.

Reading Indicators

LED light&Buzzer(adjustable tone and volume）

Typical depth of Field

Precision       Barcode          Depth of Field

3.34mil          CODE 39        60mm—160mm

3.34mil          EAN-13           90mm—150mm

5mil               CODE39          70mm—240mm

5mil               EAN-13            70mm—230mm

13mil             UPC-A              40mm—450mm

5mil               PDF417            65mm—210mm

5mil               QR                   75mm—140mm

10mil            QR                    45mm—290mm

10mil            DM                    30mm—260mm

20mil            QR                    20mm—480mm

(The minimum depth of field is determined by the barcode length and scanning angle. It depends on the print resolution, contrast and ambient light.)

Electrical Parameter

Current

Working current（Standard):

Input Voltage

5 VDC (+/- 10%)/500mA

Environmental Parameter

ESD protection(Air discharge)

8 kV

Drop resistance

Withstands repeated drops from 1.2m/4.0 ft onto a concrete surface.

Temperature

Working: 0 to 40 °C

Storage/Transport: -40 to 70 °C

Humidity(non-condensing)

5 - 95%

Ambient light

Indoor: 0 to 6,000 lux; Outdoor: 0 to 86,000 lux

Cordless Parameter

Transmission distance

100m for 2.4G in open space

Communication mode

Wireless real-time transmission/wired transmission/storage mode

Battery capacity

2000mAh

Continuous working time

＞12H

Charging time

4-5H
