Light Source

LED White light

Aiming Light

Green Dot

Image Sensor

1280*800 pixels

CPU

1.2G Dual-core

Image Speed

60FPS

Resolution(maximum)

4mil

Minimum Print Contrast

20% Reflection Difference

Image Field of View

Horizontal: 50°; Vertical: 38°

Reading Angle

Pitch: 0-360°; Roll(Tilt): ±60°; Skew (Yaw): ±60°

Decoding Capability

1D

All standard 1D codes including GS1 DataBar™ linear code can be automatically distinguished and decoded.

2D

Aztec Code; Data Matrix; Maxi Code; QR Code; HAN XIN; Micro QR Code

Stack code

GS1 DataBar Expanded Stacked; GS1 DataBar Stacked; GS1 DataBar Stacked Omnidirectional; GS1 DataBar Composite; MicroPDF417; PDF417

Reading Indicators

LED light&Buzzer(adjustable tone and volume)

Typical depth of Field

Precision

Barcode

Depth of Field

3.34mil

CODE128

60mm-160mm

5mil

CODE128

65mm-230mm

3.34mil

EAN-13

60mm-150mm

5mil

EAN-13

70mm-230mm

13.34mil

EAN-13

40mm-450mm

5mil

PDF417

65mm-210mm

10mil

DM

30mm-260mm

20mil

DM

20mm-480mm

Electrical Parameter

Current

Input Voltage

5 VDC (+/- 10%)/500mA

Environmental Parameter

ESD protection

8 kV

Drop resistance

Withstands repeated drops from 1.2m/4.0 ft onto a concrete surface.

Temperature

Working: -10 to 50 °C

Storage/Transport: -20 to 70 °C

Humidity(non-condensing)

5 - 95%

Ambient light

Indoor: 0 to 6,000 lux; Outdoor: 0 to 100,000 lux

Cordless Parameter

Transmission Mode

Wireless 2.4G and Bluetooth interface

Transmission Distance

2.4G is 100m, Bluetooth is 50m in open space

Battery Capacity

2000mAh

Working Time

It can continuous working over 12 hours

Charging time

4~5HOURS
