Light Source

LED White light

Aiming Light

Green Dot

Image sensor

640*480 pixels Global Shutter

CPU

1.2G Dual core

Resolution(maximum)

3mils

Motion Tolerance

2m/s

Print contrast ratio(minimum)

20% Reflection Difference

Image Field of View

Horizontal: 50°; Vertical: 38°

Reading Angle

Pitch: 0-360°; Roll(Tilt): ±60°; Skew (Yaw): ±60°

Decoding Capability

1D: All standard 1D codes including GS1 DataBar™ linear code can be automatically distinguished and decoded.

2D: Aztec Code; Data Matrix; MaxiCode; QRCode; HANXIN; MicroQR Code

Stack code: GS1 DataBar Expanded Stacked; GS1 DataBar Stacked; GS1 DataBar Stacked Omnidirectional; GS1 DataBar Composite; MicroPDF417; PDF417.

Reading Indicators

LED light&Buzzer(adjustable tone and volume）

Typical depth of Field

Precision Barcode  Depth of Field

3.34mil CODE 128 40mm—80mm

5mil  CODE128  35mm—135mm

3.34mil EAN-13  40mm—80mm

5mil  EAN-13  30mm—105mm

13.34mil EAN-13  30mm—290mm

5mil  PDF417  35mm—105mm

Precision Barcode  Depth of Field

15mil QR        20mm—155mm

10mil DM      30mm—140mm

20mil QR      30mm—265mm

(The minimum depth of field is determined by the barcode length and scanning angle. It depends on the print resolution, contrast and ambient light.)

Electrical Parameter

Current

Working current(Standard):

Input Voltage

5 VDC (+/- 10%)/500mA

Environmental Parameter

ESD protection(Air discharge)

8 kV

Drop resistance

Withstands repeated drops from 1.2m/4.0 ft onto a concrete surface.

Particulate and water sealing

IP52

Temperature

Working: 0 to 40 °C

Storage: -40 to 70 °C

Humidity(non-condensing)

5 - 95%

Ambient light

Indoor: 0 to 6,000 lux; Outdoor: 0 to 100,000 lux

Cordless Parameter

Cordless mode

2.4G, Bluetooth

Transmission distance

2.4G: 100 meters; Bluetooth: 50m (basic on open space)

Communication mode

Wireless real-time transmission/wired transmission/storage mode

Battery capacity

2000mAh

Continuous working time

＞12H

Charging time

4~5H

Warranty

Warranty

2 years
