Performance Parameter

Material

ABS+PC

Light Source

LED White Light

Image sensor

640*480 pixels Global Shutter

Resolution(maximum)

4mil

Print contrast ratio(minimum)

≥15%

CPU

1G

Imaging Speed

120 fps

Motion tolerance

1.2M/sec

Reading Angle

Pitch: 0-360°; Roll(Tilt): ±60°; Skew (Yaw): ±60°

Decoding Capability

1D

All standard 1D codes, including GS1 DataBar™ linear code can be automatically distinguished and decoded.

2D

Aztec Code; Data Matrix; MaxiCode; QRCode; HANXIN; MicroQR Code

Stack code

GS1 DataBar Expanded Stacked; GS1 DataBar Stacked; GS1 DataBar Stacked Omnidirectional; GS1 DataBar Composite; MicroPDF417; PDF417

Reading Indicators

LED light & Buzzer(adjustable tone and volume)

Typical Depth of Field

Precision

Barcode

Depth of Field

(The minimum depth of field is determined by the barcode length and scanning angle. It depends on the print resolution, contrast and ambient light.)

5mil

CODE128

40mm—110mm

5mil

EAN-13

40mm—110mm

13.34mil

EAN-13

65mm—300mm

5mil

PDF417

40mm—100mm

10mil

PDF417

30mm—210mm

15mil

PDF417

30mm—310mm

20mil

DM

20mm—110mm

Physical Characteristics

Color

White/Blue

Dimensions(L*W*H)

77*100*123mm

Weight

209g

Cable

1.55m

Electrical Parameter

Current

Working current(Standard):

Standby current(Standard):

Input Voltage

5 VDC (+/- 10%)/500mA

Environmental Parameter

ESD protection(Air discharge)

8 kV

Drop resistance

Withstands repeated drops from 1.2m/4.0 ft onto a concrete surface.

Particulate and water sealing

IP52

Temperature

Operation: -20 to 40 °C

Storage/Transport: -40 to 70 °C

Humidity(non-condensing)

5 - 95%

Ambient light

0 -100,000 lux

Interfaces

RS-232; USB HID; USB COM; HID POS available as per customer’s needs
