Light Source

LED White light

Aiming Light

Green Dot

Image Sensor

1280*800 pixels

CPU

1.2G Dual-core

Resolution(maximum)

≥4mil

Minimum Print Contrast

20% Reflection Difference

Image Field of View

Horizontal: 50°; Vertical: 38°

Reading Angle

Pitch: 0-360°; Roll(Tilt): ±60°; Skew (Yaw): ±60°

Decoding Capability

1D

All standard 1D codes including GS1 DataBar™ linear code can be automatically distinguished and decoded.

2D

Aztec Code; Data Matrix; Maxi Code; QR Code; HAN XIN; Micro QR Code

Stack code

GS1 DataBar Expanded Stacked; GS1 DataBar Stacked; GS1 DataBar Stacked Omnidirectional; GS1 DataBar Composite; MicroPDF417; PDF417

Reading Indicators

LED light&Buzzer(adjustable tone and volume)

Typical depth of Field

Precision

Barcode

Depth of Field

3.34mil

CODE128

60mm-160mm

5mil

CODE128

65mm-230mm

3.34mil

EAN-13

60mm-150mm

5mil

EAN-13

70mm-230mm

13.34mil

EAN-13

40mm-450mm

5mil

PDF417

65mm-210mm

10mil

DM

30mm-260mm

20mil

DM

20mm-480mm

Electrical Parameter

Current

Input Voltage

5 VDC (+/- 10%)/500mA

Environmental Parameter

ESD protection

8 kV (Air discharge)

Drop resistance

Withstands repeated drops from 1.2m/4.0 ft onto a concrete surface.

Temperature

Working: -10 to 50 °C

Storage/Transport: -20 to 70 °C

Humidity(non-condensing)

5 - 95%

Ambient light

Indoor: 0 to 6,000 lux; Outdoor: 0 to 100,000 lux
