Light Source

LED White light

Aiming Light

Green Dot

Image sensor

640*480 pixels

Resolution(maximum)

0.102mm / 4mils

Print contrast ratio(minimum)

≥20%

Reading Angle

Pitch: 0-360°; Roll(Tilt): ±60°; Skew (Yaw): ±60°

Decoding Capability

1D: All standard 1D codes, including GS1 DataBar™ linear code can be automatically distinguished and decoded.

2D: Aztec Code; Data Matrix; MaxiCode; QRCode; HANXIN; MicroQR Code

Stack code: GS1 DataBar Expanded Stacked; GS1 DataBar Stacked; GS1 DataBar Stacked Omnidirectional; GS1 DataBar Composite; MicroPDF417; PDF417.

Reading Indicators

LED light&Buzzer(adjustable tone and volume）

Typical depth of Field

Precision   Barcode      Depth of Field

3.34mil      CODE 128  10mm—60mm

5mil           CODE128   5mm—90mm

3.34mil      EAN-13      10mm—55mm

5mil           EAN-13       5mm—85mm

13.34mil    EAN-13       20mm—190mm

5mil           PDF417       5mm—75mm

10mil         PDF417       5mm—190mm

15mil         PDF417      10mm—200mm

10mil         DM              5mm—100mm

20mil         DM              5mm—210mm

(The minimum depth of field is determined by the barcode length and scanning angle. It depends on the print resolution, contrast and ambient light.)

Electrical Parameter

Current

Working current(Standard):

Input Voltage

5 VDC (+/- 10%)/500mA

Environmental Parameter

ESD protection(Air discharge)

8 kV

Drop resistance

Withstands repeated drops from 1.2m/4.0 ft onto a concrete surface.

Temperature

Working: 0 to 40 °C

Storage/Transport: -40 to 70 °C

Humidity(non-condensing)

5 - 95%

Ambient light

Indoor: 0 to 6,000 lux; Outdoor: 0 to 86,000 lux

Interfaces

Interfaces

RS-232; USB HID; USB COM; HID POS available as per customer’s needs

Transmission

Support multi-language transmission, compatible with major operating systems, support the editing of barcode data.
