Light Source

LED White light

Aiming Light

Green Dot

Image Sensor

1280*800 pixels

CPU

1.2G Dual core

Resolution(maximum)

4mils

Minimum Print Contrast

20% Reflection Difference

Image Field of View

Horizontal: 50°; Vertical: 38°

Reading Angle

Pitch: 0-360°; Roll(Tilt): ±60°; Skew (Yaw): ±60°

Decoding Capability

1D: All standard 1D codes including GS1 DataBar™ linear code can be automatically distinguished and decoded.

2D: Aztec Code; Data Matrix; MaxiCode; QRCode; HANXIN; MicroQR Code

Stack code: GS1 DataBar Expanded Stacked; GS1 DataBar Stacked; GS1 DataBar Stacked Omnidirectional; GS1 DataBar Composite; MicroPDF417; PDF417.

Reading Indicators

LED light&Buzzer(adjustable tone and volume）

Typical depth of Field

Precision     Barcode    Depth of Field

3.34mil        CODE 39  60mm—160mm

3.34mil        EAN-13     90mm—150mm

5mil             CODE39   70mm—240mm

5mil             EAN-13     70mm—230mm

13mil           UPC-A      40mm—450mm

5mil             PDF417    65mm—210mm

5mil             QR            75mm—140mm

10mil           QR            45mm—290mm

10mil           DM            30mm—260mm

20mil           QR            20mm—480mm

(The minimum depth of field is determined by the barcode length and scanning angle. It depends on the print resolution, contrast and ambient light.)

Electrical Parameter

Current

Working current（Standard):

Input Voltage

5 VDC (+/- 10%)/500mA

Environmental Parameter

ESD protection(Air discharge)

8 kV

Drop resistance

Withstands repeated drops from 1.2m/4.0 ft onto a concrete surface.

Temperature

Working: 0 to 40 °C

Storage/Transport: -40 to 70 °C

Humidity(non-condensing)

5 - 95%

Ambient light

Indoor: 0 to 6,000 lux; Outdoor: 0 to 86,000 lux

Cordless Parameter

Transmission distance

100m for 2.4G; 50m for Bluetooth (in open space)

Communication mode

Wireless real-time transmission/wired transmission/storage mode

Battery capacity

2000mAh

Continuous working time

＞12H

Charging time

4-5H

Warranty

24 months
