Light Source

LED White light

Aiming Light

Green Dot

Image Sensor

640*480 pixels (Global Shutter)

CPU

1.2G Dual core

Resolution(maximum)

3mils

Minimum Print Contrast

20% Reflection Difference

Motion Tolerance

2M/S

Image Field of View

Horizontal: 50°; Vertical: 38°

Reading Angle

Pitch: 0-360°; Roll(Tilt): ±60°; Skew (Yaw): ±60°

Decoding Capability

1D: All standard 1D codes including GS1 DataBar™ linear code can be automatically distinguished and decoded.

2D: Aztec Code; Data Matrix; MaxiCode; QRCode; HANXIN; MicroQR Code

Stack code: GS1 DataBar Expanded Stacked; GS1 DataBar Stacked; GS1 DataBar Stacked Omnidirectional; GS1 DataBar Composite; MicroPDF417; PDF417.

Reading Indicators

LED light&Buzzer(adjustable tone and volume）

Typical depth of Field

Precision       Barcode         Depth of Field

3.34mil          CODE 128     40mm—80mm

5mil               CODE128      35mm—135mm

3.34mil          EAN-13          40mm—80mm

5mil               EAN-13          30mm—105mm

13.34mil        EAN-13          30mm—290mm

5mil               PDF417         35mm—105mm

15mil             QR                 20mm—155mm

10mil             DM                 30mm—140mm

20mil             QR                 30mm—265mm

(The minimum depth of field is determined by the barcode length and scanning angle. It depends on the print resolution, contrast and ambient light.)

Electrical Parameter

Current

Working current（Standard):

Input Voltage

5 VDC (+/- 10%)/500mA

Environmental Parameter

ESD protection(Air discharge)

8 kV

Drop resistance

Withstands repeated drops from 1.2m/4.0 ft onto a concrete surface.

Temperature

Working: 0 to 40 °C

Storage/Transport: -40 to 70 °C

Humidity(non-condensing)

5 - 95%

Ambient light

Indoor: 0 to 6,000 lux; Outdoor: 0 to 86,000 lux

Cordless Parameter

2.4 Transmission distance

Open space 100 meters

Communication mode

Wireless real-time transmission/wired transmission/storage mode

Battery capacity

2000mAh

Continuous working time

＞12H

Charging time

4-5H

Warranty

24 months
