Light Source

Laser

Type of Light Source

650nm

Resolution(maximum)

0.102mm / 4mils

Print contrast ratio(minimum)

≥20%

Reading Angle

Pitch: 0-360°; Roll(Tilt): ±60°; Skew (Yaw): ±60°

Decoding Capability

AN-13, EAN-8, UPC-A, UPC-E, ISSN, ISBN, Code39, Code 39 Full ASCII, Interleaved 2 of 5, Matrix 2 of 5, Coda bar, Code128, Code 93, Code 11, cMSI/Plessey, UK/Plessey, UCC/EAN 128, China post, GS1 DataBar, RSS, etc.

Reading Indicators

LED light&Buzzer(adjustable tone and volume）

Typical depth of Field

(The minimum depth of field is determined by the barcode length and scanning angle. It depends on the

print resolution, contrast and ambient light.)

  Precision     Depth of Filed

  5mil           40mm—105mm

  10mil         10mm—250mm

  15mil         23mm—380mm

  20mil         35mm—490mm

  30mil         30mm—650mm

Electrical Parameter

Current

Working current（Standard):

Input Voltage

5 VDC (+/- 10%)/500mA

Environmental Parameter

ESD protection(Air discharge)

8 kV

Working Temperature

0 to 40 °C

Temperature

Storage/Transport: -40 to 70 °C

Humidity(non-condensing)

5 - 95%

Ambient light

Indoor: 0 to 6,000 lux; Outdoor: 0 to 86,000 lux

Interfaces

RS-232; USB HID; USB COM

Safety Level of Laser

EN60825-1，class 1，National first-class laser safety standard

Certificates

CE, FCC, ROHS, ISO

Warranty

12 months
