Light Source

LED Red Light (Standard); (red and white; red and blue for optional)

Image sensor

CMOS

Resolution

1280*800 pixels Global Shutter

Density

3mil

Motion Tolerance

2M/S

Print Contrast

15%

Reading Angle

Pitch: 0-360°; Roll(Tilt): ±60°; Skew (Yaw): ±60°

Decoding Capability

1D: All standard 1D codes, including GS1 DataBar™ linear code can be automatically distinguished and decoded

2D: Aztec Code; Data Matrix; Maxi Code; QR Code; HAN XIN; Micro QR Code GS1 DataBar Expanded Stacked; GS1 DataBar Stacked; GS1 DataBar Stacked Omnidirectional;GS1 DataBar Composite;
MicroPDF417; PDF417

Indicator

LED Light, Beeper (Volumn Can be Adjustale)

Depth of Filed

The minimum depth of field is depends on the barcode length and scanning angle. And the print resolution, contrast and ambient light.

Mil

Code

Depth of Filed

3.34mil

CODE 128

50mm—110mm

5mil

CODE128

40mm—120mm

3.34mil

EAN-13

50mm—120mm

5mil

EAN-13

40mm—120mm

13.34mil

EAN-13

20mm—190mm

5mil

PDF417

50mm—120mm

10mil

PDF417

25mm—170mm

10mil

DM

40mm—150mm

20mil

DM

20mm—190mm

Electrical Parameter

Current

Working current(Standard):

Input Voltage

5 VDC (+/- 10%)/500mA

Environmental Parameter

ESD protection(Air discharge)

8 kV

Drop Resistance

1.2M/4.0FT

Storage Temperature

-40 to 70 °C

Working Temperature

0-40 °C

Humidity(non-condensing)

5 - 95%

Ambient light

Indoor: 0 to 6,000 lux; Outdoor: 0 to 86,000 lux

Wireless Specification

Transmission distance

2.4G: 100 meters (basic on open space)

Communication mode

Wireless real-time transmission/wired transmission/storage mode

Battery Capacity

2000mAh

Continuous working time

＞12H

IP Rate

IP52

Warranty

24months
