Light Source

LED Red light（Germany）

Image sensor

640*480 pixels

Resolution(maximum)

0.102mm / 4mils

Print contrast ratio(minimum)

≥15%

Motion tolerance

2M/sec

Reading Angle

Pitch: 0-360°; Roll(Tilt): ±60°; Skew (Yaw): ±60°

Decoding Capability

1D: All standard 1D codes, including GS1 DataBar™ linear code can be automatically distinguished and decoded.

2D: Aztec Code; Data Matrix; MaxiCode; QRCode; HANXIN; MicroQR Code

Stack code: GS1 DataBar Expanded Stacked; GS1 DataBar Stacked; GS1 DataBar Stacked Omnidirectional; GS1 DataBar Composite; MicroPDF417; PDF417.

Reading Indicators

LED light&Buzzer(adjustable tone and volume）

Typical depth of Filed

Precision Barcode  Depth of Filed

5mil  CODE128  1mm—80mm

5mil  EAN-13  1mm—80mm

13.34mil EAN-13  5mm—245mm

5mil  PDF417  5mm—70mm

10mil  PDF417  5mm—180mm

15mil  PDF417  10mm—280mm

20mil  DM   5mm—80mm

(The minimum depth of field is determined by the barcode length and scanning angle. It depends on the print resolution, contrast and ambient light.)

Physical characteristics

Color available

Black&Orange&Blue

Dimensions（L*W*H）

112*101*164mm

Weight

313g

Cable

1.6m

Electrical Parameter

Current

Working current（Standard): Standby current（Standard):

Input Voltage

5 VDC (+/- 10%)/500mA

Environmental Parameter

ESD protection(Air discharge)

8 kV

Drop resistance

Withstands repeated drops from 1.2m/4.0 ft onto a concrete surface.

Particulate and water sealing

IP52

Temperature

Operation: 0 to 40 °C

Storage/Transport: -40 to 70 °C

Humidity(non-condensing)

5 - 95%

Ambient light

0 -100,000 lux

Interfaces

Interfaces

RS-232; USB HID; USB COM; HID POS available as per customer’s needs
