Light Source

LED White light

Image sensor

640*480 pixels

Resolution(maximum)

0.102mm / 4mils

Print contrast ratio(minimum)

≥20%

Reading Angle

Pitch: 0-360°; Roll(Tilt): ±60°; Skew (Yaw): ±60°

Decoding Capability

1D: All standard 1D codes, including GS1 DataBar™ linear code can be automatically distinguished and decoded.

2D: Aztec Code; Data Matrix; MaxiCode; QRCode; HANXIN; MicroQR Code

Stack code: GS1 DataBar Expanded Stacked; GS1 DataBar Stacked; GS1 DataBar Stacked Omnidirectional; GS1 DataBar Composite; MicroPDF417; PDF417.

Reading Indicators

LED light&Buzzer(adjustable tone and volume）

The typical depth of Filed

Precision Barcode          Depth of Filed

3.34mil    CODE 128      10mm—60mm

5mil         CODE128       5mm—90mm

3.34mil    EAN-13          10mm—55mm

5mil         EAN-13           5mm—85mm

13.34mil  EAN-13           20mm—190mm

5mil         PDF417          5mm—75mm

10mil       PDF417          5mm—190mm

15mil       PDF417         10mm—200mm

10mil       DM                 5mm—100mm

20mil       DM                 5mm—210mm

(The minimum depth of field is determined by the barcode length and scanning angle. It depends on the print resolution, contrast and ambient light.)

Physical characteristics

Color available

Black

Dimensions（L*W*H）

65*91*157mm

Weight

178g

Cable

1.6m

Electrical Parameter

Current

Working current（Standard): Standby current（Standard):

Input Voltage

5 VDC (+/- 10%)/500mA

Environmental Parameter

ESD protection(Air discharge)

8 kV

Drop resistance

Withstands repeated drops from 1.2m/4.0 ft onto a concrete surface.

Particulate and water sealing

IP52

Temperature

Operation: 0 to 40 °C

Storage/Transport: -40 to 70 °C

Humidity(non-condensing)

5 - 95%

Ambient light

Indoor: 0 to 6,000 lux; Outdoor: 0 to 86,000 lux

Interfaces

Interfaces
