Light Source

LED White light

Image sensor

640*480 pixels

Resolution(maximum)

0.102mm / 4mils

Print contrast ratio(minimum)

≥20%

Reading Angle

Pitch: 0-360°; Roll(Tilt): ±60°; Skew (Yaw): ±60°

Decoding Capability

1D: All standard 1D codes, including GS1 DataBar™ linear code can be automatically distinguished and decoded.

2D: Aztec Code; Data Matrix; MaxiCode; QRCode; HANXIN; MicroQR Code

Stack code: GS1 DataBar Expanded Stacked; GS1 DataBar Stacked; GS1 DataBar Stacked Omnidirectional; GS1 DataBar Composite; MicroPDF417; PDF417.

Reading Indicators

LED light&Buzzer(adjustable tone and volume）

Typical depth of Field

Precision            Barcode              Depth of Field

3.34mil               CODE 128          10mm—60mm

5mil                    CODE128           5mm—90mm

3.34mil               EAN-13              10mm—55mm

5mil                    EAN-13              5mm—85mm

13.34mil             EAN-13              20mm—190mm

5mil                    PDF417             5mm—75mm

10mil                  PDF417             5mm—190mm

15mil                  PDF417            10mm—200mm

10mil                  DM                    5mm—100mm

20mil                  DM                     5mm—210mm

(The minimum depth of field is determined by the barcode length and scanning angle. It depends on the print resolution, contrast and ambient light.)

Physical characteristics

Color available

Black

Dimensions（L*W*H）

65*91*157mm

Weight

164g

Cable

1.6m

Electrical Parameter

Current

Working current（Standard):

Input Voltage

5 VDC (+/- 10%)/500mA

Environmental Parameter

ESD protection(Air discharge)

8 kV

Drop resistance

Withstands repeated drops from 1.2m/4.0 ft onto a concrete surface.

Particulate and water sealing

IP52

Temperature

Operation: -20 to 40 °C; Storage/Transport: -40 to 70 °C

Humidity(non-condensing)

5 - 95%

Ambient light

Indoor: 0 to 6,000 lux; Outdoor: 0 to 86,000 lux

Cordless Parameter

2.4 Transmission distance

Open space 80~100 meters

Communication mode

Wireless real-time transmission/wired transmission/storage mode

Battery capacity

2000mAh

Continuous working time

＞12H

Charging time

4-5H
